Multiboost Low Rectangular
The Multiboost Rectangular tank is the premium level design in this family. It is an ideal solution for houses and apartments where there is low mains water pressure and where pressure fluctuates. The Multiboost Simplicity Rectangular range is perfect for areas where height restrictions and access are an issue.
Features:
- Non-corrosive holding tank (WRAS approved material)
- Manual adjustable start-up pressure function
- Dry run protection with auto restart (time delay)
- 2 L water accumulator tank
- 16 amp rated controller with pressure gauge as standard
- 3 piece union on outlet (for easy maintenance for crimp piping)
Fixed Speed Option:
- Power: 240 volt, 50Hz
- Pump type: Pedrollo TOP Multi 2 (240 volt)
- Controller: Presflo Multi with integral 2 litre pressure vessel
- Current input: 3.4 amp
- Main power cable: 5mtr x 1.5mm² 3 core
- Pump dB rating: <65dB
- Access via removable lid
Connections:
- Inlet: ½” BSP
- Outlet: 1” BSP
- Overflow: 1” BSP
- Drain Off: 1" BSP
*Bypass unit recommended to be fitted on inlet supply. Available Drip Tray is also recommended to be used on installation (not included in this order)
